Insect Attractant: Four standard Sylvania F40/350BL/ECO (40 watt) lamps. Lamp replacement info.
Installation: Wall-mounted horizontally with keyhole slots. Low positioning almost always yields the best results for any ILT against flies. "Below 5 feet" is the general guideline. About 3 feet or waist high is effective and also easy to maintain.
Electrical: Six foot, 3-wire grounded power cord. Standard 115v/60 Hz.. Draws 89 watts (RMS Meter).
Maintenance: The Quadra Bear uses two glueboards. Spring-locked tray conceals glueboards, is secure, and yet easy to service. Nickle chrome guard swings up for easy access to lamps for cleaning and/or replacement. Change glueboards regularly, at least as often as codes require.
Construction Features: Frame and interior structure are aluminized steel for strength. Beautifully finished in anodized aluminum with nickle chrome guard.
Dimensions: 53 1/8" x 13 1/8" x 5 5/8"
Weight: 25.4 lbs., Ship Wt: ?? lbs.
FIVE YEAR WARRANTY:
(Excluding lamps, glueboards).
|
GLUEBOARDING INSTRUCTIONS
|
